This Modern Design Concealed Thermostatic Valve will compliment any modern bathroom suite and offers thermostatic showering via two easy-to-operate controls for temperature and flow. It is supplied with a 300mm stainless steel slim shower head, swivel joint and arm, handheld shower, and bath filler with click-push button waste.
They also come with a 10 Year Guarantee.
Key Features
- Beautiful chrome finish
- 4-piece collection - shower controls, overhead, handset, and bath filler
- The valve is manufactured from solid brass
- Easy to clean and maintain once installed
- Thermostatic control to set the desired temperature for a better shower experience
Thermostatic Valve
- Top Dial - Controls Water to 1 Outlet diverter
- Middle Dial - Controls water temperature chosen temperature maintained to within +/- 1 °C
- Bottom Dial - Controls water to 2 outlets diverter
- High-Quality Design
- Chrome Finish
- Thermostatically controlled
- Manufactured from highly durable brass
- Operating range 20 - 50 deg C with 38 deg C safety button
- Built-in non-return valves to prevent backflow and filters to protect the thermostatic mechanism
- Chosen temperature is maintained to within +/-1ºC
- Pre-set maximum temperature
- Automatic shut off in the event of water cold supply failure
- UK standard size fitting
Shower Head with Wall Arm
- 300mm Stainless Steel Slim Shower Head
- 300mm Solid Brass Arm Length
- Chrome Finish
- Subject to a minimum of 1.0 bar water pressure
Easyclean Overflow Bath Filler & Click Push Button Waste
- The overflow doubles as a bath filler tap and is connected to the waste by strong and sturdy plastic piping
- Push button bathtub waste with connecting overflow
- Combined bath filler and waste
- Easy to use - just press the waste and the waste pops up and allows the water to drain
- Modern design chrome plated finish
- Durable and solid brass construction
- Sprung Click Clack Waste
- Approx 550mm pipe
Suitable for the following water systems
- Combi-boilers
- Gravity Fed systems
- MegaFlow Systems
- Pumped systems
- Un-vented systems
- Pressurised cylinder systems
- Subject to a minimum of 1.0 bar water pressure
Package Contents
- Thermostatic Valve
- Stainless Steel Slim Showerhead
- Wall Mounted Shower Arm
- ABS Hand Held Shower
- Overflow Bath Filler with click push button waste
